Hearing Aid Test System

Electroacoustic Test

Supports all types of hearing aids including BTE, ITE, and RITE

A stable, high-accuracy and effective system

Offer a full range of testing support

Overview

CRYSOUND offers a comprehensive hearing aid test system solution. Our system complies with IEC 60118-0 (2015), IEC 60118-7 (2005), and ANSI S3.22 (2009) standards, ensuring accurate and reliable testing. It covers a range of test items, including OSPL90, HFA, FOG, RTG, and EIN, to evaluate hearing aid performance. This solution provides an optimal testing environment for assessing hearing aids

Features

Compatibility

‍Supports all types of hearing aids, including BTE, ITE, and RITE models.

Customization

The system has the capability to customize acoustic frequency response signals and test modules to meet the specific needs of R&D laboratories.

Explore More Use Cases

Test Items

Hearing Aid Test

Saturated Sound Pressure Level (SPL) OSPL90

Gain FOG50

Frequency Response Width

Equivalent Input Noise

Total harmonic distortion

Input/ Output Characteristics

Restoration Time

Battery Current

System Devices

Edit Content

CRY6151B Electroacoustic Analyzer

CRY6151B is a robust and reliable electroacoustic analyzer with a frequency range spanning from 20Hz to 20kHz. It is designed to evaluate a diverse array of devices, including USB, Bluetooth®, and noise-canceling headphones; electret, MEMS, and moving-coil microphones; receivers; speakers; Bluetooth loudspeakers; and loudspeaker crossover devices.

Technicians can assess device performance using key metrics and procedures such as sensitivity (SPL), impedance, total harmonic distortion (THD), resonance frequency (F0), headphone balance, headphone positioning, phase, polarity, microphone current and voltage, signal-to-noise ratio (SNR), microphone directivity, speaker Thiele/Small (TS) parameters, and telephone loudness ratings. The CRY6151B offers comprehensive capabilities for thorough and precise evaluation of electroacoustic equipment.

Edit Content

CRY576 Bluetooth® Dongle

CRY576 Bluetooth® Dongle is a Bluetooth device designed for Bluetooth audio and UI testing. The CRY576 is engineered for use in R&D laboratories and production lines. It is versatile, functioning seamlessly both with the CRY6151B electroacoustic tester and as a stand-alone module with other testing equipment. The CRY576 supports a range of Bluetooth solutions with high reliability and fast test speeds, connecting to most solutions in under 3 seconds. Users can operate the CRY576 via CRY6151B test software or its own stand-alone tool software to perform functions such as searching, pairing, connecting, playing audio, and recording.

Edit Content

CRY723D Pneumatic Acoustic Test Chamber

The CRY723D Pneumatic Acoustic Test Chamber is primarily used to test the power, sensitivity, and other electrical performance parameters of wireless electronic and communication products, such as wireless servers and walkie-talkies. This test chamber can be utilized with comprehensive testers, vector network analyzers, signal sources, and channel emulators to conduct essential testing. It is capable of connecting to wireless devices via Bluetooth, WiFi, GSM, WCDMA, RFID, or GPS remote controllers.

Edit Content

CRY3602 Mouth Simulator with Built-In 20dB Amplifier

CRY3602 mouth simulator is a sound source used to simulate the sound field near the human mouth. It is widely used for testing acoustic parameters such as the frequency response and distortion of telephone transmitters and microphones.

‍CRY3602 mouth simulator has a built-in power amplifier. There is no need to purchase an additional power amplifier. It can be directly connected to a sound card or signal generator, simplifying the connection of the test system.

Edit Content

CRY3711 Ear Simulator IEC60318-4

The CRY3711 ear simulator simulates the way an earplug conduit is inserted into the ear canal or auricle to measure headphone performance. It has a 1/2 inch prepolarized pressure field measurement microphone inside and can be used for acoustic testing of high-quality in-ear headphones.

‍The input impedance of CRY3711 is very close to the input impedance of an ordinary human ear, enabling effective measurement up to 10 kHz.
